Custom Designed & CNC Milled Screw Drive Gearbox Housing
|
We manufactured and integrated this drive gear box housing for use in the medical industry. Composed of 6061-T6 aluminum with a yellow iridite chromate finish, we used a 3-axis CNC machine to perform profile milling, drilling, and tapping. Next, we performed deburring. Overall, the tightest tolerance upheld was +/- .0005, with an opposing bore tolerance of +/- .0002. Upon completion, the drive gear box housing measured 4 inches long, 4 inches wide, and 3.5 inches high, with a base material thickness of 4.25 inches. |
Highlights of this Designed & CNC Milled Screw Drive Gearbox Housing
| Product Description |
This Drive Gear Box Housing is used in the Medical Industry. We manufactured and integrated this assembly. |
| Capabilities Applied/Processes |
3-Axis CNC Milling |
| Equipment Used to Manufacture Part |
Milling Machine - HAAS VMC |
| Overall Part Dimensions |
4.0 inches long x 4.0 inches wide x 3.5 inches high
Base Material 4.25 Inches Thick |
| Tightest Tolerances |
±.0005
Opposing bores with a tolerance of ±.0002 |
| Material Used |
6061-T6 Aluminum |
| Material Coating |
Yellow Iridite Chromate |
| Max Material Finish |
125 RMS |
| Typical Machining Operations |
3-Axis Milling Machine
- Profile Milling
- Drilling (Hole Patten of Axis drilled /bored within ±.0002)
- Tapping |
| Secondary Operation |
Deburring |
| In Process Testing Performed |
Critical Bores were checked on the Machine |
| Industry for Use |
Medical |
| Delivery Location(State) |
Florida |
| Standards Met |
Customer supplied print, and 3D SolidWorks Model |
| Product Name |
Drive Gear Box Housing |
